For RGB LED Strip and RGB LED Spotlight
Input Voltage: DC 12V/24V
Current Output: 10A
Max. Power Output: 72W for 12V, 144W for 24V
Output Port: 2 Channels (R G B +)
Control Mode: Common Anode
DC Power Plug: OD 5.5mm x ID 2.1mm
Sound Control: >60dB
External dimension: L86xW84xH25mm
Working Temperature: -20 to 45 Degree C.
More Multicolor Functions (Multicolor Changing Mode):
Mode 1: Each color will be displayed in flash mode
Mode 2: Single color will be displayed in flash mode
Press "CS" button, then select any color to show in flash mode.
Mode 3: This mode will be displayed in a different mixed color.
Mode 4: Each color will be displayed in a smooth change brightness.
Mode 5: Single color will be displayed in a smooth change brightness.
Press "CS" button, then select any color to show in this mode.
More Music Functions (Music Control Mode):
Mode 1: The light of this lamp will jump according to the BEAT of the music (>70dB). NO MUSIC = NO LIGHT!
Mode 2: The single color light is jumping with the music (>70 dB). NO MUSIC = NO LIGHT!
Press "CS" button, then select any color to show in this mode.Â
Mode 3: The light of this lamp will jump according to the BEAT of the music (>70 dB). When NO MUSIC, the lamp will display in a different mixed color!
Application:
1. Hotels, bars, restaurants, commercial and residential.
2. Party Rooms and multi-use rooms.
3. Any installation where easy-to-control coloured lighting.
Functions of Keys (please check the manual inside the box)
1. Increase or decrease the brightness of the light in single color mode and music control mode. Increase or decrease the speed of the light in multicolor changing mode.Â
2. Turn on/off the device.
3. Select the color.
4. To the next multicolor changing mode.
5. To the previous multicolor changing mode.
6. To the next music control mode.Â
7. To the previous music control mode.
8. Select the color in multicolor changing mode 2 and 5. Select the color in music control mode 2.
9. Pause/Start.
This controller has memory function, it re-start from the last mode once power off.
