300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
(image for) 300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light
  • Model: GY-P5V60A-E
  • Shipping Weight: 0.73kg
  • In Stock: 1000

300 Watt LED Power Supply 5V 60A LED Power Supplies AC 200 - 240V For LED Strips LED Light

$52.40
GY-P5V60A-E
Qty Discounts Off Price
1
$52.40		 2-4
$49.78		 5-14
$47.16		 15-19
$44.54		 20-49
$41.92		 50+
$39.30

(0  Reviews) Add Your Review
ModelGY-P5V60A-E OutputDc Voltage5VRated Current60ARated Power300WRipple&Noise180mvp-pVoltage ADJ.Range3.8-6.2VVoltage Tolerance±1.0%Line Regulation±0.5%Load Regulation±1.0%Setup,Rise Time300ms,50ms/230VAC 800ms,50ms/115Vac at full loadHold Up Time(typ.)90ms/230vac 12ms/115vac At...
Add to Cart:
  • This product was added to our catalog on Tuesday 03 December, 2013.
Description
ModelGY-P5V60A-E
OutputDc Voltage5V
Rated Current60A
Rated Power300W
Ripple&Noise180mvp-p
Voltage ADJ.Range3.8-6.2V
Voltage Tolerance±1.0%
Line Regulation±0.5%
Load Regulation±1.0%
Setup,Rise Time300ms,50ms/230VAC 800ms,50ms/115Vac at full load
Hold Up Time(typ.)90ms/230vac 12ms/115vac At Full Load
inputVoltage RangeAC 200 - 240V
Frequency Range47-63Hz


Ac Current(typ.)5.6A/115V  2.8A/230Vac
Inrush currentCold Start  25A/115Vac 50A/230V
leakage Current3.5mA/240VAC
ProtectionOverload105-150% rated output power
protection type:hiccup mode,recovers automatically after fault condition
115-135% rated output voltage
Over Voltage115-135% rated output voltage
Protection Type:hiccup mode,recovers automatically after fault condition
environmentWorking Temp -10~+60°c
Working Humidity20-90%rh non-condesing
Storage Temp,Humidity -20~+85°c,10-95%rh
Temp.Coefficient±0.03%°c(0-50°c)
Vibration10-500hz
Safety&EMCsafety standardCE RoHS
withstand voltageI/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC 1minute
Isolation ResistanceI/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC/25°C/70%RH
EMI Conduction&radiationDesign refer to GB4943,UL60950,EN60950
EMC StandardDesign refer to GB9254,EN55022 Class A
DimensionL220*W120*H30mm
Packing0.73kg
