24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light

Model: GY-PS-ZH-S-24-12
Availability :  In Stock
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
  • 24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
$12.54
Qty Discounts Off Price
1
$12.54		 2-4
$11.91		 5-14
$11.28		 15-19
$10.66		 20-49
$10.03		 50+
$9.40

QTY :

Model GY-PS-ZH-S-24-12
Output Dc Voltage 12V
Rated Current 2000mA
Rated Power 24W
Ripple&Noise 180mvp-p
Voltage ADJ.Range 10.8-13.2V
Voltage Tolerance ±1.0%
Line Regulation ±0.5%
Load Regulation ±1.0%
Setup,Rise Time 300ms,50ms/230VAC 800ms,50ms/115Vac at full load
Hold Up Time(typ.) 90ms/230vac 12ms/115vac At Full Load
input Voltage Range 85-264VAC 120-370VDC
Frequency Range 47-63Hz
Efficiency(typ.) 74%
Ac Current(typ.) 5.6A/115V  2.8A/230Vac
Inrush current Cold Start  25A/115Vac 50A/230V
leakage Current 3.5mA/240VAC
Protection Overload 105-150% rated output power
protection type:hiccup mode,recovers automatically after fault condition
115-135% rated output voltage
Over Voltage 115-135% rated output voltage
Protection Type:hiccup mode,recovers automatically after fault condition
environment Working Temp  -10~+60°c
Working Humidity 20-90%rh non-condesing
Storage Temp,Humidity  -20~+85°c,10-95%rh
Temp.Coefficient ±0.03%°c(0-50°c)
Vibration 10-500hz
Safety&EMC safety standard CE RoHS
withstand voltage I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC 1minute
Isolation Resistance I/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC/25°C/70%RH
EMI Conduction&radiation Design refer to GB4943,UL60950,EN60950
EMC Standard Design refer to GB9254,EN55022 Class A
Dimension L95*W44*H23mm
Packing 0.072kg

24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
24 Watt LED Power Supply 12V 2000mA LED Power Supplies UL Certification For LED Strips LED Light
