300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting
(image for) 300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting
(image for) 300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting
(image for) 300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting
(image for) 300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting
(image for) 300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting
(image for) 300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting
(image for) 300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting
  • Model: GY-PS-DO-W-300-12
  • Shipping Weight: 3.5kg
  • In Stock: 1000

300 Watt LED Power Supply 12V 25A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting

$114.99
GY-PS-DO-W-300-12
Qty Discounts Off Price
1
$114.99		 2-4
$109.24		 5-14
$103.49		 15-19
$97.74		 20-49
$91.99		 50+
$86.24

(0  Reviews) Add Your Review
ModelGY-PS-DO-W-300-12 OutputDc Voltage12VRated Current25ARated Power300WRipple&Noise180mvp-pVoltage ADJ.Range 10.8-13.2VVoltage Tolerance±1.0%Line Regulation±0.5%Load Regulation±1.0%Setup,Rise Time300ms,50ms/230VAC 800ms,50ms/115Vac at full loadHold Up Time(typ.)90ms/230vac...
Add to Cart:
  • This product was added to our catalog on Friday 23 May, 2014.
Description
ModelGY-PS-DO-W-300-12
OutputDc Voltage12V
Rated Current25A
Rated Power300W
Ripple&Noise180mvp-p
Voltage ADJ.Range 10.8-13.2V
Voltage Tolerance±1.0%
Line Regulation±0.5%
Load Regulation±1.0%
Setup,Rise Time300ms,50ms/230VAC 800ms,50ms/115Vac at full load
Hold Up Time(typ.)90ms/230vac 12ms/115vac At Full Load
inputVoltage Range85-264VAC 120-370VDC
Frequency Range47-63Hz
Efficiency(typ.)74%
Ac Current(typ.)5.6A/115V  2.8A/230Vac
Inrush currentCold Start  25A/115Vac 50A/230V
leakage Current3.5mA/240VAC
ProtectionOverload105-150% rated output power
      protection type:hiccup mode,recovers automatically after fault condition
      115-135% rated output voltage
Over Voltage115-135% rated output voltage
Protection Type:hiccup mode,recovers automatically after fault condition
environmentWorking Temp -10~+60°c
Working Humidity20-90%rh non-condesing
Storage Temp,Humidity -20~+85°c,10-95%rh
Temp.Coefficient±0.03%°c(0-50°c)
Vibration10-500hz
Safety&EMCsafety standardCE RoHS
withstand voltageI/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC 1minute
Isolation ResistanceI/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC/25°C/70%RH
EMI Conduction&radiationDesign refer to GB4943,UL60950,EN60950
EMC StandardDesign refer to GB9254,EN55022 Class A
DimensionL330*W115*H45mm
Packing3.5kg
