(image for) 200 Watt LED Power Supply 12V 16.7A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting

200 Watt LED Power Supply 12V 16.7A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting

Model: GY-PS-DO-W-200-12-1
Shipping Weight: 2.36kg
In Stock: 1000

200 Watt LED Power Supply 12V 16.7A LED Power Supplies Waterproof IP67 For LED Strips LED Lighting

$72.50

GY-PS-DO-W-200-12-1

Qty Discounts Off Price
1 $72.50	2-4 $68.88	5-14 $65.25	15-19 $61.63	20-49 $58.00	50+ $54.38

(0 Reviews) Add Your Review

ModelGY-PS-DO-W-200-12-1 OutputDc Voltage12VRated Current16.7ARated Power200WRipple&Noise180mvp-pVoltage ADJ.Range 10.8-13.2VVoltage ToleranceÂ±1.0%Line RegulationÂ±0.5%Load RegulationÂ±1.0%Setup,Rise Time300ms,50ms/230VAC 800ms,50ms/115Vac at full loadHold Up Time(typ.)90ms/230vac...

This product was added to our catalog on Friday 23 May, 2014.

Description

Model		GY-PS-DO-W-200-12-1
Output	Dc Voltage	12V
	Rated Current	16.7A
	Rated Power	200W
	Ripple&Noise	180mvp-p
	Voltage ADJ.Range	10.8-13.2V
	Voltage Tolerance	Â±1.0%
	Line Regulation	Â±0.5%
	Load Regulation	Â±1.0%
	Setup,Rise Time	300ms,50ms/230VAC 800ms,50ms/115Vac at full load
	Hold Up Time(typ.)	90ms/230vac 12ms/115vac At Full Load
input	Voltage Range	85-264VAC 120-370VDC
	Frequency Range	47-63Hz
	Efficiency(typ.)	74%
	Ac Current(typ.)	5.6A/115V Â 2.8A/230Vac
	Inrush current	Cold Start Â 25A/115Vac 50A/230V
	leakage Current	3.5mA/240VAC
Protection	Overload	105-150% rated output power Â Â Â protection type:hiccup mode,recovers automatically after fault condition Â Â Â 115-135% rated output voltage Â Â Â
	Over Voltage	115-135% rated output voltage
		Protection Type:hiccup mode,recovers automatically after fault condition
environment	Working Temp	-10~+60Â°c
	Working Humidity	20-90%rh non-condesing
	Storage Temp,Humidity	-20~+85Â°c,10-95%rh
	Temp.Coefficient	Â±0.03%Â°c(0-50Â°c)
	Vibration	10-500hz
Safety&EMC	safety standard	CE RoHS
	withstand voltage	I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC 1minute
	Isolation Resistance	I/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC/25Â°C/70%RH
	EMI Conduction&radiation	Design refer to GB4943,UL60950,EN60950
	EMC Standard	Design refer to GB9254,EN55022 Class A
	Dimension	L227W115H46mm
	Packing	2.36kg
