13inch 0.33Meter 12W LED Bar Fixture Double Row 5630 48LED 1680 Lumens Cabinet LED Bar Light Kits

724Light LD-RG-SH051-kit033 series13inch(330mm) 12W LED Bar Fixture uses high power SMD 5630 LEDs to produce up to 1680lumens/bar. The LD- RG-SH051-Kit series is ideal for cabinet , stairs, parking lots, garages, tunnels, or any other house Interior . Safe 12V DC operation , 100% 6030 aluminium channel . Available in Pure White and Warm white with wide flood 120 degree beam patterns. support custom desgin(info@724light.com)

Product Specifications
Part number:	LD-RG-SH051-Kit033
Wattage:	12W/pcs
Compares to:	20W Fluorescent
Kits include Bar:	2/3/4/5/6/7/8/9/10/11/12 pcs optional
Color Temperature:	Pure White(6000-6500k),Warm White(2700-3500k)
Lumen:	1680 Lumens/bar(35Lumens/leds)
LED Type:	SMD 5630
LED Quantity:	1*24PCS
Beam Angle:	Approx. 120°
CRI:	75 CR
Operating Temperature:	-40~+50 °C
Materials:	Aluminum/Stainless Steel
Operating Voltage:	12 DC
Length:	13inch(330mm)
Wire Connector:	2000mm OneSide 2Pin Power Cord with connector
Lifetime:	40000 Hours
Standards And Certifications:	CE/FCC/ROHS Compliant
Warranty:	2 Years
Weight(Net):	0.097 kg/bar
Dimensions(LxWxH):	13inch(330mm) x 23.5mm x 16.88mm
Package Weight:
Install :	direct install3 with power supply , clip and screw
Packaging list:
1)LED Bar (according your choose pcs) 2)LED Power Supply (according your choose pcs ) 2PCS--12V 2A 3PCS--12V 3A 4PCS--12V 3A 5PCS--12V 4A 6PCS--12V 5A 7PCS--12V 6A 8PCS--12V 6A 9PCS--12V 8A 10PCS--12V 8A 11PCS--12V 10A 12PCS--12V 10A 3)Install Clip and screw

ALL LD-RG-SH051 Series (One pcs Bar)

Part Number	Length	Lumens	Watts	Compares to	LEDS	Weight
LD-RG-SH051-Kit033	13inch(330mm)	1680 Lumens	12W	20W Fluorescent	48 Pcs 5360LEDs	0.097Kg
LD-RG-SH051-Kit050	19.7 inch(500mm)	2520 Lumens	18W	30W Fluorescent	72 Pcs 5360LEDs	0.145Kg
LD-RG-SH051-Kit100	39.3inch(1000mm)	5040 Lumens	36W	60W Fluorescent	144 Pcs 5360LEDs	0.29Kg
