Product Notice
*2 / 3 / 4 / 5 Feet G13 Bi-pin
*Aluminum + PC housing
*CRI80 100LM/W
*Non-dimmable
*12V-36V T8 LED Tube, the tube can work with power from 12V, 24V and 36V.
*Ideal for 12-36V DC Automotive RV Marine lighting system.
*DO NOT put into 110V, check the voltage what you currently have to avoid return or pop up.
STOP: These light cannot be used on a 120v AC fixture.
•Turn off the RV main power (battery disconnect button). Ensure the lights will not illuminate before proceeding
•Remove the tubes. Some tubes pull straight down, others need to be rotated 90 degrees and then pulled down.
STOP: Before proceeding, test fit the new LED tube lights in your fixture with the fixture diffuser cover on.
Do not turn power on to the fixture when test fitting. Remove the pin protectors to test fit the tube. Remove the new LED tube after test fitting and continue
Tube Dimension
Length---- Wattage---- Diameter
2feet------- 10W------ 26mm
3feet------- 15W------ 26mm
4feet------- 18W------ 26mm
Feature
*2 Feet T8 Tube
*G13 Bi-pin base
*Dual-end power feed
*CRI80,100LM/W
*12V-36V T8 LED Tube, the tube can work with power from 12V, 24V and 36V.
*Ideal for 12-36V DC Automotive RV Marine lighting system.
* DO NOT put into 110V, check the voltage what you currently have to avoid return or pop up.
