(image for) DC12-24V 288-576W RGB High Speed Power Amplifier 3 Channels 24A Output Current Common Anode For LED Strip

DC12-24V 288-576W RGB High Speed Power Amplifier 3 Channels 24A Output Current Common Anode For LED Strip

Model: LD-TAC-080-A
Shipping Weight: 0.28kg
In Stock: 885

DC12-24V 288-576W RGB High Speed Power Amplifier 3 Channels 24A Output Current Common Anode For LED Strip

$13.13

LD-TAC-080-A

Qty Discounts Off Price
1-4 $13.13	5-9 $11.81	10-19 $11.16	20-49 $10.50	50-99 $9.84	100+ $9.19

(0 Reviews) Add Your Review

Summarization RGB amplifier applies to all the voltage-controlled LED controller in our company, it can receives PWM(Pulse Width Modulation), each time add one RGB amplifier, the connecting number of led will be more than twice, in theory, numerous RGB amplifiers can be connected. Technical...

This product was added to our catalog on Thursday 05 December, 2013.

Description

Summarization

RGB amplifier applies to all the voltage-controlled LED controller in our company, it can receives PWM(Pulse Width Modulation), each time add one RGB amplifier, the connecting number of led will be more than twice, in theory, numerous RGB amplifiers can be connected.

Technical parameters

1. Work temperature: -20-60 degree

2. Supply voltage: DC12-24V

3. Size: 98*45*18mmÂ Â Â Â Â Â Â Â Â Â

4. Package size:105*65*40mm

5. Carton size: L496*W272*H308mmÂ Â Â Â Â

6. Output: 3 channel (R/G/B/+)

7. Connecting mode: common anode

8. Static power: : <1WÂ Â Â

9. Output current : < 8A(each channel)Â Â Â

10. Output power: 12V< 288W,Â 24V<576W

11. Input / output optical isolation, not common ground
