RF touch controller adopts the advanced micro control unit, it is used for controlling a variety of lamp whose source of light is LED. For instance, point source of light, flexible light strip, wall washer lamp, glass curtain wall light and so on; it has many advantages such as touch remote control, easy connection and simplicity to use. Meanwhile, you can adjust brightness, static color choices and various dynamic changes in lighting effects through wireless touch remote control. And accorking to the actual need of customjers, It can carry out jumpy changing, gradual changing, stroboflash and other effects of change.
- Specifications
- RGB Controller,RGB Controller
- 1.Touch-button,ultrathin,light quality
- 2.Wireless remote controller
- 3.rgb controller
- RGB Controller ,RGB Controller ,Touching RGB led panel controller,rgb led controller
- Technical Parameters
- working temperature: -20-60 °C
- supply voltage: 12V -24V
- output: 3 channels
- connection mode: common anode
- external dimension: L110ΧW42ΧH27mm
- packing size: L130 Χ W100 Χ H40 mm
- et weight: 500g
- gross weight: 550g
- static power: <1W
- output current: <4A( each channel )
- output power: 12V<108W,24V<216W
- output: 3 channels
- Changes of M key on the touch remote as below
