5050 SMD LED Modules 75x12MM 12V 0.75W 5050 3 LED Modules Waterproof Modules

Price: Starting at: $0.54

  • Model: MD-3X5050-7512-S   Weight:0.007Kg

Please Choose:

LED Color









about led white
Qty Discounts Off Price
20-99
$0.54
100-499
$0.49
500-999
$0.46
1,000-1,999
$0.43
2,000-4,999
$0.41
5,000+
$0.35

* Discounts may vary based on options above
if order over 500 ,price is $0.36 Wholesale Free shipping>>
Add to Cart:   Min:  20 Units:  20
buy now
Shipping To  us start at $1.82,Over $100 Free shipping

Description:


LED Type: 3 x SMD 5050
Size(mm): 75x12MM
Light Color: Pure White/Warm White/Cold White/Blue/Red/Green/Yellow
Input: 12V DC
Power(W) 0.75w/pcs
Min Cutting: 1pcs
Waterproof IP65
Length(Row): 310cm(122inch)
Luminous: 18-20lm/led
Luminous(Row): 1200lm
Life: 50,000 hrs
Materials: Plastic
Temperature: -40℃- 60℃ (-40℉~140℉)
Wire Length : the lines of the two module light is 8cm(3.15inch)
Package: 20pcs in one string, 100pcs in one package

The LED Module power consumption calculation: If the power is 0.75W each LED, one string power is 20x0.75W.(Suggest 24w or 36w power supply)


5050 SMD LED Modules 75x12MM 12V 0.75W 5050 3 LED Modules Waterproof Modules
5050 SMD LED Modules 75x12MM 12V 0.75W 5050 3 LED Modules Waterproof Modules
5050 SMD LED Modules 75x12MM 12V 0.75W 5050 3 LED Modules Waterproof Modules

5050 SMD LED Modules 75x12MM 12V 0.75W 5050 3 LED Modules Waterproof Modules

5050 SMD LED Modules 75x12MM 12V 0.75W 5050 3 LED Modules Waterproof Modules Video

C 5050 Single Color LED Module Lights

ImagesPart Number SMD LED Lumen/LED Lumen/String Module String VoltsSize(WXL) Power Consumption Wire Length Total Length Color
MD-3X5050-7512-S led module light MD-3X5050-7512-S5050 18~20 Lumen 1200 lumen 20pcs12V75x12MM 0.75W/PCS 8cm 310cm rgb
LD-MODR-5050S7512-5-PB led module light LD-MODR-5050S7512-5-PB5050 18~20 Lumen1200 lumen 20pcs12V75x12MM 1.25W/PCS 8cm 310cm rgb
MD-4X5050-3636-S led module light MD-4X5050-3636-S505018~20 Lumen 1600 lumen20pcs12V36x36MM 1W/PCS8cm 232cm rgb
GY-ML-SMD5050-02 led module light GY-ML-SMD5050-025050 18~20 Lumen1600 lumen20pcs12V36x36MM1W/PCS8cm 232cm rgb
GY-ML-SMD5050-01 led module light GY-ML-SMD5050-01505018~20 Lumen 400 lumen 20pcs12V20x12MM 0.24W/PCS 8cm 200cm rgb
MD-2X5050-4512-S led module light MD-2X5050-4512-S5050 18~20 Lumen 800 lumen 20pcs12V45x12MM 0.5W/PCS 160cm 250cm rgb
MD-3X5050-7815-S led module light MD-3X5050-7815-S505018~20 Lumen 1200 lumen 20pcs12V78x15MM 0.75W/PCS 8cm 316cm rgb
MD-4X5050-3232-S-M led module light MD-4X5050-3232-S-M5050 18~20 Lumen 1600 lumen 20pcs12V32x32MM 0.96W/PCS 8cm 224cm rgb
MD-3X5050-7512-S-2 led module light MD-3X5050-7512-S-2505018~20 Lumen 1200 lumen 20pcs12V 75x12MM 0.75W/PCS 8cm 310cm rgb
MD-3X5050-6518-S led module light MD-3X5050-6518-S5050 18~20 Lumen 1200 lumen 20pcs12V 65x18MM 0.75W/PCS 8cm 290cm rgb

C 3528 Single Color LED Module Lights

ImagesPart Number SMD LED Lumen/LED Lumen/String Module String VoltsSize(WXL) Power Consumption Wire Length Total Length Color
MD-2X3528-2607-S led module light MD-2X3528-2607-S 3528 6~7 Lumen 280 lumen 20pcs12V26x0.7MM 0.2W/PCS 5cm 152cm rgb
GY-ML-SMD3528-P-01 led module light GY-ML-SMD3528-P-01 3528 6~7 Lumen 420 lumen 20pcs12V 66x12MM 0.5W/PCS 5cm 224cm rgb
GY-ML-SMD3528-S-01 led module light GY-ML-SMD3528-S-01 3528 6~7 Lumen 560 lumen 20pcs12V 35x35MM 0.5W/PCS 5cm 170cm rgb

C 5630 Single Color LED Module Lights

ImagesPart Number SMD LED Lumen/LED Lumen/String Module String VoltsSize(WXL) Power Consumption Wire Length Total Length Color
MD-4X5630-3636-S led module light MD-4X5630-3636-S 5630 55~60 Lumen 4800 lumen 20pcs12V36x36MM 2W/PCS 8cm 260cm rgb
MD-3X5630-7815-S led module light MD-3X5630-7815-S 5630 55~60 Lumen 3600 lumen 20pcs12V 78x15MM 1.5W/PCS 8cm 316cm rgb
GY-ML-SMD5630-P-01 led module light GY-ML-SMD5630-P-01 5630 55~60 Lumen 4200 lumen 20pcs12V 36x36MM 0.24W/PCS 8cm 232cm rgb
MD-3X5630-7512-S led module light MD-3X5630-7512-S 5630 55~60 Lumen 3600 lumen 20pcs12V 75x12MM 1.5W/PCS 8cm 310cm rgb

C RGB LED Module Lights

ImagesPart Number SMD LED Lumen/LED Lumen/String Module String VoltsSize(WXL) Power Consumption Wire Length Total Length Color
MD-3X5050-7512-RGB led module light MD-3X5050-7512-RGB 5050 18~20 Lumen 1200 lumen 20pcs12V75x12MM 0.75W/PCS 8cm 310cm rgb
MD-3X5050-6815-RGB led module light MD-3X5050-6815-RGB 5050 18~20 Lumen 1200 lumen 20pcs12V 65x18MM 0.75W/PCS 8cm 290cm rgb
MD-3X5050-3232-RGB-M led module light MD-3X5050-3232-RGB-M 5050 18~20 Lumen 1200 lumen 20pcs12V 32x32MM 0.96W/PCS 8cm 224cm rgb
MD-3X5050-7513-RGB led module light MD-3X5050-7513-RGB 5050 18~20 Lumen 1200 lumen 20pcs12V 75x13MM 0.75W/PCS 8cm 310cm rgb
MD-3X5050-6820-RGB led module light MD-3X5050-6820-RGB 5050 18~20 Lumen 1200 lumen 20pcs12V 68x20MM 0.75W/PCS 8cm 296cm rgb
MD-3X5050-7513-RGB led module light MD-3X5050-7513-RGB 5050 18~20 Lumen 1200 lumen 20pcs12V 75x13MM 0.75W/PCS 8cm 310cm rgb
MD-4X5050-3232-W-RGB led module light MD-4X5050-3232-W-RGB 5050 18~20 Lumen 1600 lumen 20pcs12V 32x32MM 0.75W/PCS 8cm 224cm rgb

UL certification LED Module Lights

ImagesPart Number SMD LED Lumen/LED Lumen/String Module String VoltsSize(WXL) Power Consumption Wire Length Total Length Color
GY-LMOD-LL-F12P600W1L50 led module light GY-LMOD-LL-F12P600W1L50 Nichia LED 105 lumens 2100 lumen 20pcs12V 55x30MM 1W/PCS 10cm 325cm rgb
GY-LMOD-LL-F12P600W1L50-3 led module light GY-LMOD-LL-F12P600W1L50-3 Nichia LED 120 lumens 2400 lumen 20pcs 24V 50x30MM 1.2W/PCS 10cm 325cm rgb
GY-LL-F12T7314W3A led module light GY-LL-F12T7314W3A 2835 Everlight led 60-66 lumens 3960 lumen 20pcs12V 66x15MM 0.72W/PCS 8cm 315cm rgb
GY-LMOD-F12T4508W3B led module light GY-LMOD-F12T4508W3B 3528 Everlight LED     15pcs12V 45x8MM 0.24W/PCS 5cm 184cm rgb
GY-LMOD-LL-F12T4508R3B led module light GY-LMOD-LL-F12T4508R3B 3528 Epistar LED     15pcs12V 45x8MM 0.24W/PCS 5cm 184cm rgb
GY-LMOD-OS5630-PB led module light GY-LMOD-OS5630-PB Osram SMD5630 57.6 lumens 3456lumens 20pcs 12V 78x15MM 1.2W/PCS 13cm 440cm rgb

Other LED Module Lights

ImagesPart Number SMD LED Lumen/LED Lumen/String Module String VoltsSize(WXL) Power Consumption Wire Length Total Length Color
MD-RGB-12-RGB led module light MD-RGB-12-RGB RGB Piercing Light     20pcs12V12mm 0.5W/PCS     rgb
GY-LMOD-OS14-PB led module light GY-LMOD-OS14-PB Nichia LED 90~110 lumens 2200 lumen 20pcs12V 40x35MM 1W/PCS 10cm 280cm rgb
MD-F8-12-S led module light MD-F8-12-S F8 Piercing Light     20pcs12V 12MM 0.15W/PCS     rgb
