39.3inch 1Meter 36W LED Bar Fixture Double Row 5630 144LED 5040 Lumens Cabinet LED Bar Light Kits

Model: LD-RG-SH051-kit100
Availability :  In Stock
  • 39.3inch 1Meter 36W LED Bar Fixture Double Row 5630 144LED 5040 Lumens Cabinet LED Bar Light Kits
  • 39.3inch 1Meter 36W LED Bar Fixture Double Row 5630 144LED 5040 Lumens Cabinet LED Bar Light Kits
  • 39.3inch 1Meter 36W LED Bar Fixture Double Row 5630 144LED 5040 Lumens Cabinet LED Bar Light Kits
  • 39.3inch 1Meter 36W LED Bar Fixture Double Row 5630 144LED 5040 Lumens Cabinet LED Bar Light Kits
  • 39.3inch 1Meter 36W LED Bar Fixture Double Row 5630 144LED 5040 Lumens Cabinet LED Bar Light Kits
  • 39.3inch 1Meter 36W LED Bar Fixture Double Row 5630 144LED 5040 Lumens Cabinet LED Bar Light Kits
  • 39.3inch 1Meter 36W LED Bar Fixture Double Row 5630 144LED 5040 Lumens Cabinet LED Bar Light Kits
$60.70
LED Color

Kits Bar Quantity

Quantity Discount
5 - 9
$57.67		10 - 14
$56.45		15 - 19
$55.24		20 +
$54.63
QTY :

724Light LD-RG-SH051-kit100 series 39.3inch(1000mm)36W LED Bar Fixture uses high power SMD 5630 LEDs to produce up to 5040lumens/bar. The LD-RG-SH051-kit100 series is ideal for cabinet , stairs, parking lots, garages, tunnels, or any other house Interior . Safe 12V DC operation , 100% 6030 aluminium channel . Available in Pure White and Warm white with wide flood 120 degree beam patterns. support custom desgin([email protected])

Product Specifications
Part number: LD-RG-SH051-Kit033
Wattage: 36W/pcs
Compares to: 60W Fluorescent
Kits include Bar: 3/4/5/6 pcs optional
Color Temperature:Pure White(6000-6500k),Warm White(2700-3500k)
Lumen: 5040 Lumens/bar(35Lumens/leds)
LED Type: SMD 5630
LED Quantity: 1*144PCS
Beam Angle:Approx. 120°
CRI:75 CR
Operating Temperature:-40~+50 °C
Materials:Aluminum/Stainless Steel
Operating Voltage: 12 DC
Length: 39.3inch(1000mm)
Wire Connector: 2000mm OneSide 2Pin Power Cord with connector
Lifetime:40000 Hours
Standards And Certifications:CE/FCC/ROHS Compliant
Warranty:2 Years
Weight(Net): 0.29 kg/bar
Dimensions(LxWxH): 39.3inch(1000mm) x 23.5mm x 16.88mm
Package Weight:
Install : direct install with power supply , clip and screw
Packaging list:
1)LED Bar (according your choose pcs)
2)LED Power Supply (according your choose pcs )
  • 3PCS--12V 5A
  • 4PCS--12V 6A
  • 5PCS--12V 8A
  • 6PCS--12V 10A
3)Install Clip and screw
2

ALL LD-RG-SH051 Series (One pcs Bar)

Part Number Length Lumens Watts Compares to LEDS Weight
LD-RG-SH051-Kit033 13inch(330mm) 1680 Lumens 12W 20W Fluorescent 48 Pcs 5360LEDs 0.097Kg
LD-RG-SH051-Kit050 19.7 inch(500mm) 2520 Lumens 18W 30W Fluorescent 72 Pcs 5360LEDs 0.145Kg
LD-RG-SH051-Kit100 39.3inch(1000mm) 5040 Lumens 36W 60W Fluorescent 144 Pcs 5360LEDs 0.29Kg
